Performance Specifications:- SJ-20
Symbol | Description | Dimention (MM) | Dimention (ft,in") |
---|---|---|---|
A | Load Over height | 6380 | 21'10" |
B | Pin Height (Max) | 5440 | 17'10" |
C | Dump Height | 4780 | 15'8" |
D | Reach at Full Dump(depend upon tractor) | 999 | 3'3" |
E | Reach at Ground(depend upon tractor) | 1520 | 5' |
F | Jaw opening | 1150 | 3'9" |
G | Surface plane opening jaw height | 1130 | 3'9" |
Safe Working Load | 1500KG |
